22mm 25mm digital Voltmeter Ammeter indicator light

Application

Feature：

Size:Φ22 / 25mm
Shape:panel round hole installation, short body compact
Using Features:increase the circuit board three anti-technology, moisture, dust, anti-corrosion.
Advantages:mass production of the patch process, cost-effective, low power consumption, wide range of applications;
set anti-touch terminal security cover IP20;
comply with RoHS environmental directives;
access to CE certification; accept OEM, ODM customized services.

Function :

Mini Voltmeter Ammeter indicator light, signal lights
only two lines of measurement and power supply, three digital display AC and DC voltage, wide measurement voltage AC65 ~ 480V (red light), DC9 ~ 36V (green light);
increase the exchange (red light) and DC (green light) ammeter, four-wire operation;
increase the symbol display indicator V / dc, V / ac, A / dc, A / ac; A / dc is out of stock.
ammeter can be used as a load disconnection instructions with more ingenious;

Specification

Model	SMV-A	SMV-D	SMA-D	SMA-A
Type of input	DC voltage	AC voltage	DC current	AC current
Measurement / power supply range	DC9~36V	AC65~480V 50/60Hz	0~36A	0~50A
Measurement / power supply range	DC9~36V	Valid values	External shunt	External transformer
Digital Display	00.0~36.0	000~480	00.0~36.0	00.0~50.0
Digital Display	Vdc	Vac	Adc	Aac
Indicates the color	green	red	green	red
measurement accuracy	±0.1V	±1%	±0.1A	±5%
Terminals	2×M3.5Screw		4×M3.5Screw
The sampling period	0.5s
Display method	3-digit 7-segment digital tube
Power consumption	Maximum 10mA
