Item : C45N DZ47-63
Mini Circuit breaker
Product name : Mini Circuit breaker 6-63 Amp MCB
DZ47-63 6-63 amp circuit breaker
32 amp mcb C45N series circuit breaker is used in lighting distribution system or motor distribution system for protection overload and short-circuits in the system. MCB is neoteric in structure, light in weight, reliable and excellent in performance. MCB has high breaking capacity, can trip quickly, and its case and items are adopted by high fire-resistant and shockproof plastics. The product , with long life, is mainly used in AC 50/60HZ single-pole 240 or two, three four-pole 415V circuit for overload and short-circuit protection as well as for unfrequented on –and-off switching electric equipment and lighting circuit in normal case. The products comply with IEC 60898 &BS 3771.
| Standard | Rated current(A) | Pole | Voltage(V) | Breaking capacity(A) |
| BS3871-1 IEC60898 | 1 TO 40 50 TO 63 | 1 | 240 | 6000 |
| 2,3,4 | 415 | 6000 | ||
| 50 TO 63 | 1 | 240 | 4000 | |
| 2,3,4 | 415 | 4000 | ||
| IEC157-1 | 1 | 1 | 220/240 | 10000 |
| 2,3,4 | 220/240 | 20000 | ||
| 2,3,4 | 380/415 | 10000 | ||
| 3 | 1 | 220/240 | 8000 | |
| 2,3,4 | 220/240 | 20000 | ||
| 2,3,4 | 380/415 | 8000 | ||
| 10 to 40 | 1 | 220/240 | 7000 | |
| 2,3,4 | 220/240 | 16000 | ||
| 2,3,4 | 380/410 | 8000 | ||
| 50 | 1 | 220/240 | 6000 | |
| 2,3,4 | 220/240 | 10000 | ||
| 2,3,4 | 380/410 | 6000 | ||
| 63 | 1 | 220/240 | 5000 | |
| 2,3,4 | 220/240 | 10000 | ||
| 2,3,4 | 380/410 | 5000 |
| Standard | Rated current(A) | Pole | Voltage(V) | Breaking capacity(A) |
| S3871-1 IEC60898 | 1 to 40 | 1 | 240 | 4000 |
| 2,3,4 | 415 | 4000 | ||
| IEC157-1 | 1 to 40 | 1 | 220/240 | 6000 |
| 2,3,4 | 220/240 | 12000 | ||
| 2,3,4 | 380/415 | 6000 |
